Brand：CEDRAT
Internal functions of an optical communication terminal (OCT) for aerospace space optical links. The design is optimized to meet the harsh environments and low recurring cost requirements of the new aerospace market.
|
Active axis |
- |
RX, RY |
RX, RY |
RX, RY |
|
Angular displacement |
mrad (+/-) |
18 |
50 |
140 |
|
Loaded resonance frequency |
Hz |
700 |
100 |
100 |
|
Angular resolution |
μrad |
2 |
0,5 |
20 |
|
Voltage range |
V |
-20...150 |
||
|
Capacitance (per electrical port) |
μF |
3 |
? |
? |
|
Dimensions |
mm |
63x61x30 |
Ø45x40 |
Ø62x60 |
|
Mass |
g |
135 |
195 |
500 |
|
Sensor Option |
- |
SG |
ECS |
ECS |
