Brand：PHOTRON CRYSTA
Model :
PI-300 / WPI-200
WPI-200
Polarized camera that can acquire all polarization information. You can measure DOP, which indicates the degree of polarization, and distinguish between clockwise and counterclockwise circular polarization. A revolutionary camera that can acquire Stokes parameters that indicate the state of polarization.
PI-300
PI cameras are capable to obtain polarization information real-time, as a normal image, and at high-resolution.They are used in many areas including recognition of dark objects using their polarization signature, real-time polarization monitoring of laser beams, etc.
Polarized camera that can acquire all polarization information. You can measure DOP, which indicates the degree of polarization, and distinguish between clockwise and counterclockwise circular polarization. A revolutionary camera that can acquire Stokes parameters that indicate the state of polarization.
PI-300
PI cameras are capable to obtain polarization information real-time, as a normal image, and at high-resolution.They are used in many areas including recognition of dark objects using their polarization signature, real-time polarization monitoring of laser beams, etc.
PI-300 WPI-200
This is a camera capable of capturing polarized light image videos. It is particularly useful for identifying the contours of objects with minimal brightness differences and measuring the polarization of lasers. PI (Polarization Imaging) measures the degree of linear polarization and the principal axis direction, while WPI (Wideband Polarization Imaging) measures Stokes parameters.
Observation of Surface Irregularities
Even when brightness differences are too subtle for the naked eye to detect, polarized light images can reveal minute irregularities.
Brightness Image
Polarized Light Image
Makes it easier to identify surface irregularities.
Evaluation of New Fiber Materials
Using reflected light, the fiber orientation of materials like CFRP (carbon fiber reinforced polymer) can be visually evaluated as the direction of the polarizing principal axis.
Evaluation of New Fiber Materials
WPI (Wideband Polarization Imaging) for Full Polarization Information
Traditional polarization cameras (e.g., PI) cannot obtain complete polarization data.
WPI measures the Degree of Polarization (DOP) and distinguishes between clockwise and counterclockwise circularly polarized light.
WPI is a revolutionary camera that acquires Stokes parameters indicating the polarization state.
Upper right blue image: "Clockwise circularly polarized light"
Lower right red image: "Counterclockwise circularly polarized light"
